| Type |
Horizontal Triplex Single
Acting Piston Pump |
Gear Type |
Herringbone |
| Rated Power, HP (kW) |
500 (373) |
Gear Ratio |
4.286:1 |
| Rated Pump Speed, SPM |
165 |
Maximum Liner Size by Stroke Length, inches (mm) |
6-3/4" x 7-1/2 " (171 x 191) |
| Suction Connection, inches (mm) |
8" ( 203) |
Valve Pot |
API # 5 |
| Discharge Connection |
4" ( 102 mm ) 5,000
psi (34.5 MPa) Flange |
Approximate Weight, lbs (kg) |
21,539 (9,770) |
|
|
Liner Size, inches (mm) |
6-3/4
(171) |
6-1/2
(165) |
6
(152) |
5-1/2
(140) |
5
(127) |
4
(102) |
Rated Pressure
psi (MPa) |
1,342
(9.3) |
1,447
(10.0) |
1,699
(11.7) |
2,020
(13.9) |
2,442
(16.8) |
3,820
(26.3) |
|
Pump Speed, SPM |
Input Power
HP (kW) |
Displacement, GPM (LPM ) |
|
165 |
500
(373) |
575
(2,177) |
533
(2,018) |
454
(1,718) |
382
(1,446) |
316
(1,196) |
202
(764) |
|
150 |
455
(339) |
523
(1,980) |
485
(1,836) |
413
(1,564) |
347
(1,313) |
287
(1,087) |
184
(697) |
|
140 |
424
(316) |
488
(1,847) |
452
(1,711) |
386
(1,461) |
324
(1,226) |
268
(1,015) |
171
(647) |
|
130 |
394
(294) |
453
(1,715) |
420
(1,590) |
358
(1,355) |
301
(1,139) |
249
(943) |
159
(602) |
|
120 |
364
(271) |
418
(1,582) |
388
(1,469) |
330
(1,249) |
278
(1,052) |
229
(867) |
147
(556) |
110 |
334
(249) |
383
(1,450) |
356
(1,348) |
303
(1,147) |
255
(965) |
210
(795) |
135
(511) |
|
Volume/Stroke, gallons (liters) |
3.49
(13.21) |
3.23
(2.23) |
2.75
(10.41) |
2.31
(8.74) |
1.91
(7.23) |
1.22
(4.62) |
|
