| Type |
Horizontal Triplex Single
Acting Piston Pump |
Gear Type |
Herringbone |
| Rated Power, HP (kW) |
2,200 (1,640) |
Gear Ratio |
3.512:1 |
| Rated Pump Speed, SPM |
105 |
Maximum Liner Size by Stroke Length, inches (mm) |
9" x 14" (229 x 356) |
| Suction Connection, inches (mm) |
12" (305) |
Valve Pot |
API # 8 |
| Discharge Connection |
5-1/8" ( 130 mm ) 5,000
psi (34.5 MPa) Flange |
Approximate Weight, lbs (kg) |
64,815 (29,400) |
|
|
Liner Size, inches (mm) |
9
(229) |
8-1/4
(210) |
7-1/2
(191) |
7
(178) |
6
(152) |
5-1/2
(140) |
Rated Pressure
psi (MPa) |
2,760
(19.0) |
3,310
(22.8) |
4,040
(27.9) |
4,505
(31.0) |
5,000
(34.5) |
5,000
(34.5) |
|
Pump Speed, SPM |
Input Power
HP (kW) |
Displacement, GPM (LPM ) |
|
105 |
2,200
(1,640) |
1,231
(4,659) |
1,026
(3,884) |
840
(3,179) |
754
(2,854) |
524
(1,982) |
456
(1,726) |
|
90 |
1,886
(1,406) |
1,055
(3,994) |
880
(3,329) |
720
(2,725) |
646
(2,446) |
449
(1,699) |
391
(1,480) |
|
80 |
1,676
(1,250) |
938
(3,550) |
782
(2,959) |
640
(2,422) |
574
(2,174) |
399
(1,510) |
347
(1,315) |
|
70 |
1,467
(1,094) |
820
(3,106) |
684
(2,590) |
560
(2,120) |
503
(1,903) |
349
(1,321) |
304
(1,151) |
|
60 |
1,257
(937) |
703
(2,662) |
586
(2,219) |
480
(1,817) |
431
(1,631) |
299
(1,132) |
261
(986) |
50 |
1,048
(781) |
586
(2,218) |
489
(1,850) |
400
(1,514) |
359
(1,359) |
249
(944) |
217
(822) |
|
Volume/Stroke, gallons (liters) |
11.72
(44.37) |
9.77
(36.99) |
8.00
(30.28) |
7.18
(27.18) |
4.99
(18.88) |
4.34
(16.44) |
|
