| Type |
Horizontal Triplex Single
Acting Piston Pump |
Gear Type |
Herringbone |
| Rated Power, HP (kW) |
1,000 (746) |
Gear Ratio |
4.207:1 |
| Rated Pump Speed, SPM |
140 |
Maximum Liner Size by Stroke Length, inches (mm) |
6-3/4" x 10" (171 x 254) |
| Suction Connection, inches (mm) |
10" (254) |
Valve Pot |
API # 6 |
| Discharge Connection |
5-1/8" ( 130 mm ) 5,000
psi (34.5 MPa) Flange |
Approximate Weight, lbs (kg) |
41,425 (18,790) |
|
|
Liner Size, inches (mm) |
6-3/4
(171) |
6-1/2
(165) |
6
(152) |
5-1/2
(140) |
5
(127) |
4
(102) |
Rated Pressure
psi (MPa) |
2,370
(16.3) |
2,558
(17.6) |
3,000
(20.7) |
3,572
(24.6) |
4,322
(29.8) |
5,000
(34.5) |
|
Pump Speed, SPM |
Input Power
HP (kW) |
Displacement, GPM (LPM ) |
|
140 |
1,000
(746) |
651
(2,464) |
603
(2,282) |
514
(1,946) |
432
(1,635) |
357
(1,351) |
289
(1,094) |
|
130 |
928
(692) |
604
(2,287) |
560
(2,120) |
477
(1,805) |
401
(1,518) |
331
(1,253) |
269
(1,018) |
|
120 |
857
(639) |
558
(2,112) |
517
(1,957) |
441
(1,669) |
370
(1,400) |
306
(1,159) |
248
(939) |
|
110 |
785
(585) |
511
(1,934) |
474
(1,794) |
404
(1,529) |
339
(1,283) |
280
(1,060) |
227
(859) |
|
100 |
714
(532) |
465
(1,760) |
431
(1,631) |
367
(1,389) |
309
(1,169) |
255
(965) |
207
(784) |
90 |
642
(479) |
418
(1,582) |
388
(1,469) |
330
(1,249) |
278
(1,052) |
229
(867) |
186
(704) |
|
Volume/Stroke, gallons (liters) |
4.65
(17.60) |
4.31
(16.31) |
3.67
(13.89) |
3.09
(11.69) |
2.55
(9.65) |
2.07
(7.84) |
|
